NEXT H9 IP Chrome





NEXT H9 IP Chrome is an elegant battery uplighter with mirror finish. It is equipped with 9 x10W RGBWAUV hex color led, and have very bright output for outdoor applications.



NEXT H9 IP Chrome has a built-in rechargeable lithium-ion battery fully protected against overcharging to maximize battery life span.



This fixture uses a very stable wireless DMX transceiver. The fixture can also be controlled with infrared remote controller. The IR controller can help users to achieve all working functions.



NEXT H9 IP has sturdy aluminum body and is durable to provide you with years of service. Its chrome housing can help to immerge itself into surroundings and makes your event looking more professional and impressive.

  • - Rechargeable lithium-ion battery;



    - Battery protection against overcharging, hence to ensure battery lifespan;



    - Aluminum chrome housing for temporary outdoor applications;



    - RGBWAUV 6-in-1 high power led for vivid color mixing;



    - 100% true wireless DMX transceiver;



    - OLED display with touch buttons for easy addressing and setup;



    - Infrared remote control;



    - Modular design for easy and fast maintenance;



    - Tilt adjustable 25°.

  • Electrical





    Power input



    100-240VAC 50/60Hz(Charge case)

    Power consumption



    50W

    Power connector



    Charge base

    Battery





    Battery type



    11.1V 13Ah

    Recharge time

    		   Around 4.5 hours

    Battery life

    		   Around 5 hours to run full color



    		   Around 8 hours to mix colors



    		   Around 20 hours to run single color

    Light sources





    Led



    9x10W, RGBWA+UV hex color

    Beam angle



    12°

    Field angel



    25°

    Led average life span



    Over 50,000 hours

    Control





    Control mode



    DMX512,Master/Slave, Auto Run,
    Wireless DMX; Infrared remote control

    DMX channel



    6/8/12 channels

    Control panel

    		   OLED with touch button

    Physical & Construction





    Housing



    Aluminum

    Housing color



    Chrome

    Fixture dimensions



    136 x 136 x 185mm

    Net weight



    2.6 kg

    Working temperature



    -10° - 40°C

    IP rating



    Top: IP65; Base: IP54
    Cooling    Natural cooling, silent operation
                               Packing
    Charge case    6 or 8-pack charge case
