Led Star Curtain 7x5m White Led

This led curtain is a full color LED star curtain system. It features 192 pcs super bright RGB 3-in-1 LEDs. LEDs are scattered randomly on a 7x5m drape to make real star sky effects.

The led star curtain has its own control system - one controller box StarLED and one driver box. StarLED is an interface to operate the whole system. StarLED controller has a two-row LCD display from which the user can configurate the system easily. The controller has 3-pin and 5-pin XLR DMX input /output ports, and can meet different control requirements via DMX desks.

StarLED controller has two data outputs with 4-pin XLR sockets. The data outputs supply the leds with data and power. The driver box is already embedded in the led curtain. It drives 8 groups LED lamps in the curtain. Each group with 28 pcs RGB LED lamps. Users need to connect StarLED controller and driver box with enclosed 4-pin data cable.

- Heavy duty fireproof molton fabric (SGS certified);

- Super bright white led to create vivid starry effects;

- 8 groups of led individually programmable;

- Unique design for fast replacing faulty led without tools;

- 10 preset programs;

- Multiple control modes;

- 3-pin and 5-pin XLR output connectors;

- High quality controller box with built-in MeanWell power supply.

Electrical
Power input	85~132VAC, 176~264VAC, 47~63Hz
Power supply	100W 7.5V
Power consumption	48W max
Power fuse	2A
Data fuse	10A max
Photometric
Light source	192 pcs ¢5 super bright white LEDs
Led lifetime	80,000 hours
Effects
Dimming	0-100% RGB dimming
Strobe	Fast strobe (speed adjustable), sound-activated
Program	17 pre-set programmers, built-in color macros
	Auto run programs with speed adjustable
	8 groups of LEDs controllable separately for various effects
Control
Control mode	DMX512,Master/Slave,AutoRun, Sound activation,
DMX channel	12 DMX channels
DMX connector	3-pin and 5-pin XLR input/output ports
Control panel	LCD display, control panel lockable
Physical & Construction
Curtain materia	Fire retardant heavy duty cloth
Curtain size	7,000 x 5,000 mm
Curtain net weight	21.5 kg
Gross weight	24.0 kg (incl. controller and cables)
Curtain color	Black
Controller
Controller material	Metal
Controller box size	248L x 148W x 43.2H mm
Net weight	1.8 kg
Controller color	Black
Environmental
Operating temp.	0℃ ~ 50℃
Operating humidity	<80% RH
Storage temp.	0℃ ~ 50℃
Storage humidity	<60% RH
